TWIN 860
Revolutionary 2-in-1 SOLUTION for grinding of
-
metal-cutting circular saw blades with CBN-abrasive grinding
-
carbide tipped metal and wood circular saw blades
- Space-saving concept
- Two different grinding processes in ONE machine
- High degree of automation
- Excellent, uniform grinding quality
- Complete machining with only one grinding wheel
- chip breaker slots grinding up to 710 mm (optional)
Working range HSS
Saw blade Ø | 60 – 860 mm |
Chamfering Ø | > 75 mm |
Tooth pitch | 1 – 40 mm |
Cutting width | 8 mm |
Rake angles | 0 – +27 degrees |
Clearance angles | +4 – +16 degrees |
Chamfer / bevel angles | 45 degrees |
Working range TK (Carbide/Cermet Tipped)
Saw blade Ø | 200 – 500 mm |
Chamfering Ø | > 210 mm |
Tooth pitch | 1 – 40 mm |
Cutting width | 5 mm |
Rake angles | -30 – +20 degrees |
Clearance angles | +4 – +16 degrees |
Chamfer / bevel angles | 45 degrees |
Working range TCT (Tungsten-Carbide-Tipped)
Saw blade Ø | 145 – 700 mm |
Chamfering Ø | > 145 mm |
Tooth pitch | 6 – 60 mm |
Cutting width | 5 mm |
Rake angles | -10 – +25 degrees |
Clearance angles | 0 – +25 degrees |
Chamfer / bevel angles | 0 – +45 degrees |
